Tree

"Tree is a non-linear data structure which organizes data in hierarchical structure and this is a recursive definition."

"Tree data structure is a collection of data (Node) which is organized in hierarchical structure recursively"

In tree data structure, every individual element is called as Node. Node in a tree data structure stores the actual data of that particular element and link to next element in hierarchical structure.

Terminology

In a tree data structure, we use the following terminology...

1. Root

In a tree data structure, the first node is called as Root Node. Every tree must have a root node. We can say that the root node is the origin of the tree data structure. In any tree, there must be only one root node. We never have multiple root nodes in a tree.

2. Edge

In a tree data structure, the connecting link between any two nodes is called as EDGE. In a tree with 'N' number of nodes there will be a maximum of 'N-1' number of edges.

3. Parent

In a tree data structure, the node which is a predecessor of any node is called as PARENT NODE. In simple words, the node which has a branch from it to any other node is called a parent node. Parent node can also be defined as "The node which has child / children".

4. Child

In a tree data structure, the node which is descendant of any node is called as CHILD Node. In simple words, the node which has a link from its parent node is called as child node. In a tree, any parent node can have any number of child nodes. In a tree, all the nodes except root are child nodes.

5. Siblings

In a tree data structure, nodes which belong to same Parent are called as SIBLINGS. In simple words, the nodes with the same parent are called Sibling nodes.

6. Leaf

In a tree data structure, the node which does not have a child is called as LEAF Node. In simple words, a leaf is a node with no child.

In a tree data structure, the leaf nodes are also called as External Nodes. External node is also a node with no child. In a tree, leaf node is also called as 'Terminal' node.

7. Internal Nodes

In a tree data structure, the node which has atleast one child is called as INTERNAL Node. In simple words, an internal node is a node with atleast one child.

In a tree data structure, nodes other than leaf nodes are called as Internal Nodes. The root node is also said to be Internal Node if the tree has more than one node. Internal nodes are also called as 'Non-Terminal' nodes.

8. Degree

In a tree data structure, the total number of children of a node is called as DEGREE of that Node. In simple words, the Degree of a node is total number of children it has. The highest degree of a node among all the nodes in a tree is called as 'Degree of Tree'

9. Level

In a tree data structure, the root node is said to be at Level 0 and the children of root node are at Level 1 and the children of the nodes which are at Level 1 will be at Level 2 and so on... In simple words, in a tree each step from top to bottom is called as a Level and the Level count starts with '0' and incremented by one at each level (Step).

10. Height

In a tree data structure, the total number of edges from leaf node to a particular node in the longest path is called as HEIGHT of that Node. In a tree, height of the root node is said to be height of the tree. In a tree, height of all leaf nodes is '0'.

11. Depth

In a tree data structure, the total number of egdes from root node to a particular node is called as DEPTH of that Node. In a tree, the total number of edges from root node to a leaf node in the longest path is said to be Depth of the tree. In simple words, the highest depth of any leaf node in a tree is said to be depth of that tree. In a tree, depth of the root node is '0'.

12. Path

In a tree data structure, the sequence of Nodes and Edges from one node to another node is called as PATH between that two Nodes. Length of a Path is total number of nodes in that path. In below example the path A - B - E - J has length 4.

13. Sub Tree

In a tree data structure, each child from a node forms a subtree recursively. Every child node will form a subtree on its parent node.

Applications of trees

The following are the applications of trees:

• Storing naturally hierarchical data: Trees are used to store the data in the hierarchical structure. For example, the file system. The file system stored on the disc drive, the file and folder are in the form of the naturally hierarchical data and stored in the form of trees.
• Organize data: It is used to organize data for efficient insertion, deletion and searching. For example, a binary tree has a logN time for searching an element.
• Trie: It is a special kind of tree that is used to store the dictionary. It is a fast and efficient way for dynamic spell checking.
• Heap: It is also a tree data structure implemented using arrays. It is used to implement priority queues.
• B-Tree and B+Tree: B-Tree and B+Tree are the tree data structures used to implement indexing in databases.
• Routing table: The tree data structure is also used to store the data in routing tables in the routers.

Types of Tree data structure

The following are the types of a tree data structure:

• General tree: The general tree is one of the types of tree data structure. In the general tree, a node can have either 0 or maximum n number of nodes. There is no restriction imposed on the degree of the node (the number of nodes that a node can contain). The topmost node in a general tree is known as a root node. The children of the parent node are known as subtrees.


  There can be n number of subtrees in a general tree. In the general tree, the subtrees are unordered as the nodes in the subtree cannot be ordered.
  Every non-empty tree has a downward edge, and these edges are connected to the nodes known as child nodes. The root node is labeled with level 0. The nodes that have the same parent are known as siblings.
• Binary Tree: Here, binary name itself suggests two numbers, i.e., 0 and 1. In a binary tree, each node in a tree can have utmost two child nodes. Here, utmost means whether the node has 0 nodes, 1 node or 2 nodes.


• Binary Search Tree: Binary search tree is a non-linear data structure in which one node is connected to n number of nodes. It is a node-based data structure. A node can be represented in a binary search tree with three fields, i.e., data part, left-child, and right-child. A node can be connected to the utmost two child nodes in a binary search tree, so the node contains two pointers (left child and right child pointer).
  Every node in the left subtree must contain a value less than the value of the root node, and the value of each node in the right subtree must be bigger than the value of the root node.

A node can be created with the help of a user-defined data type known as struct, as shown below:

struct node
{
    int data;
    struct node *left;
struct node *right;
}

The above is the node structure with three fields: data field, the second field is the left pointer of the node type, and the third field is the right pointer of the node type.

• AVL Tree


It is one of the types of the binary tree, or we can say that it is a variant of the binary search tree. AVL tree satisfies the property of the binary tree as well as of the binary search tree. It is a self-balancing binary search tree that was invented by Adelson Velsky Lindas. Here, self-balancing means that balancing the heights of left subtree and right subtree. This balancing is measured in terms of the balancing factor.

We can consider a tree as an AVL tree if the tree obeys the binary search tree as well as a balancing factor. The balancing factor can be defined as the difference between the height of the left subtree and the height of the right subtree. The balancing factor's value must be either 0, -1, or 1; therefore, each node in the AVL tree should have the value of the balancing factor either as 0, -1, or 1.

• Red-Black Tree


The red-Black tree is the binary search tree. The prerequisite of the Red-Black tree is that we should know about the binary search tree. In a binary search tree, the value of the left-subtree should be less than the value of that node, and the value of the right-subtree should be greater than the value of that node. As we know that the time complexity of binary search in the average case is log₂n, the best case is O(1), and the worst case is O(n).

When any operation is performed on the tree, we want our tree to be balanced so that all the operations like searching, insertion, deletion, etc., take less time, and all these operations will have the time complexity of log₂n.

The red-black tree is a self-balancing binary search tree. AVL tree is also a height balancing binary search tree then why do we require a Red-Black tree. In the AVL tree, we do not know how many rotations would be required to balance the tree, but in the Red-black tree, a maximum of 2 rotations are required to balance the tree. It contains one extra bit that represents either the red or black color of a node to ensure the balancing of the tree.

• Splay tree

The splay tree data structure is also binary search tree in which recently accessed element is placed at the root position of tree by performing some rotation operations. Here, splaying means the recently accessed node. It is a self-balancing binary search tree having no explicit balance condition like AVL tree.

It might be a possibility that height of the splay tree is not balanced, i.e., height of both left and right subtrees may differ, but the operations in splay tree takes order of logN time where n is the number of nodes.

Splay tree is a balanced tree but it cannot be considered as a height balanced tree because after each operation, rotation is performed which leads to a balanced tree.

• Treap

Treap data structure came from the Tree and Heap data structure. So, it comprises the properties of both Tree and Heap data structures. In Binary search tree, each node on the left subtree must be equal or less than the value of the root node and each node on the right subtree must be equal or greater than the value of the root node. In heap data structure, both right and left subtrees contain larger keys than the root; therefore, we can say that the root node contains the lowest value.

In treap data structure, each node has both key and priority where key is derived from the Binary search tree and priority is derived from the heap data structure.

The Treap data structure follows two properties which are given below:

• Right child of a node>=current node and left child of a node <=current node (binary tree)
• Children of any subtree must be greater than the node (heap)

• B-Tree


B-tree is a balanced m-way tree where m defines the order of the tree. Till now, we read that the node contains only one key but b-tree can have more than one key, and more than 2 children. It always maintains the sorted data. In binary tree, it is possible that leaf nodes can be at different levels, but in b-tree, all the leaf nodes must be at the same level.

If order is m then node has the following properties:

• Each node in a b-tree can have maximum m children
• For minimum children, a leaf node has 0 children, root node has minimum 2 children and internal node has minimum ceiling of m/2 children. For example, the value of m is 5 which means that a node can have 5 children and internal nodes can contain maximum 3 children.
• Each node has maximum (m-1) keys.

The root node must contain minimum 1 key and all other nodes must contain atleast ceiling of m/2 minus 1 keys.
